Servomex has expert solutions for polyethylene production

Polyethylene

The polyethylene process requires a high-quality product while maintaining high standards of process safety. The highly accurate, reliable measurements provided by Servomex gas analyzers, using cutting-edge sensing technologies, ensure the highest standards of product purity, highly responsive process control, and dependable safety across the production process.

Maintaining feedstock gas quality

An exceptionally flexible material, polyethylene is widely used in consumer and industrial applications around the world. It is produced by polymerizing the gas ethylene. The ethylene feedstock is treated to remove moisture and other residual gases, and combined with hydrogen and a co-monomer in a reaction system. The quality of these feedstock gases is essential to process efficiency and to protect the expensive catalyst from trace contamination.

Measurements for safety and purity

The primary contaminants present in the polyethylene production process are oxygen (O2) and carbon dioxide (CO2). It is also important to monitor O2 for safety. Polymerization is a highly exothermic reaction, so it requires continuous cooling to prevent undesirable side-reactions, creating a challenging environment for gas analysis. Additionally, the product stream requires accurate gas analysis – including the measurement of total hydrocarbons – to ensure safety in the headspace by ensuring the concentration stays below its lower explosive limit.

A rugged solution for essential measurements

A highly flexible, high-performance analytical solution for a wide range of gases, the SERVOTOUGH SpectraExact 2500 uses Infrared and Gas Filter Correlation sensing technologies to deliver the real-time online monitoring needed for both purity and safety in polyethylene production. Fully certified for continuous measurement of flammable samples, the resilience and flexible measurement architecture of the SpectraExact 2500 helps ensure accurate monitoring of CO2 impurities and total hydrocarbons in the form of n-hexane. It also provides essential ethylene concentration measurements to assure feedstock purity.

A safety-enhanced oxygen analysis solution

For accurate measurements of oxygen contamination in the feedstock, Servomex supplies the SERVOTOUGH Oxy 1900. Designed to operate with accuracy in hazardous conditions, this gas analyzer offers the enhanced reliability of stable, non-depleting Paramagnetic sensor technology. A heated sample compartment provides unrivaled stability and simplified sampling. The Oxy 1900 can also be used to monitor oxygen for safety in the catalyst feed, and in the final product stream.

Servomex analyzer finder

Refine by search term

Refine selection by:

4900 Multigas

SERVOPRO Safe Area

The 4900 Multigas is a high-performance CEMS analyzer designed for a wide range of multi-gas measurements.

  • Advanced digital multi-gas CEMS analysis
  • Up to four simultaneous gas stream measurements
  • Ultra-stable, accurate, non-depleting sensors
  • Auto-calibration for reduced operational needs
  • Intuitive-use icon-driven colour touchscreen
  • Digital communications for remote access

AquaXact 1688

SERVOPRO Safe Area

A rugged ultra-thin film Aluminum Oxide moisture sensor which measures moisture in a wide variety of gas phase process applications.

SERVOPRO AquaXact 1688
  • Fast and accurate moisture measurements
  • Rugged ultra-thin film Aluminium Oxide sensor
  • Functions as a standalone 4-20mA transmitter
  • Remotely interfaces with compatible controller or analyser
  • Sensor element is NIST-traceable and field-replaceable
  • IP65-rated connector

AquaXact Controller

SERVOPRO Safe Area

Built specifically to work in harmony with the AquaXact 1688 ultra-thin film Aluminum Oxide moisture transmitter.

  • Specifically designed to operate AquaXact 1688
  • High-clarity colour touchscreen display
  • Alarms, relays, and advanced communications
  • Allows easy sensor tip replacement in the field
  • Powerful, intuitive software control
  • Compact and easy to integrate into your system

Chroma

SERVOPRO Safe Area

The Chroma is optimized to specific background gases to ensure optimum performance for your application.

  • Versatile, ultra-accurate trace gas analysis
  • Choice of non-depleting sensor technologies
  • Cost-effective solution for process control or quality monitoring
  • Works in a wide range of background gases
  • Compact 4U rack-compatible design
  • Flexible communication options

DF-550E NanoTrace

SERVOPRO Safe Area

An ultra-trace Coulometric oxygen analyzer, the DF-550E is optimized for quality measurements in ultra-high-purity electronic gases.

DF-550E an ultra-trace Coulometric oxygen analyzer.
  • An ultra-trace Coulometric oxygen analyser
  • For quality measurements in electronic gases
  • 200 parts-per-trillion Lower Detection Limit
  • Suitable for use with multiple background gases
  • Unaffected by sample and flow rate changes
  • Hand-carry portable option

DF-560E NanoTrace ULTRA

SERVOPRO Safe Area

A superior quality control solution for ultra-high-purity (UHP) electronic grade gases, the DF-560E Ultra delivers an industry-best detection of 45 parts per trillion for oxygen (O2).

SERVOPRO DF-560E ULTRA
  • Delivers industry-best oxygen measurements
  • For quality control in ultra-high-purity gases
  • Lower Detection Limit of 45 parts-per-trillion
  • High-stability Coulometric sensing technology
  • Optimised for ease of use and portability
  • Cost-effective setup and configuration

DF-745

SERVOPRO Safe Area

The DF-745 delivers trace and ultra-trace measurements of moisture for ultra-high-purity (UHP) electronic gas checks in LED/LCD manufacturing processes.

  • Delivers trace/ultra-trace moisture measurements
  • For electronic gas checks in LED/LCD manufacturing
  • Can monitor multiple background gases
  • Lower Detection Limit of 1 part per billion
  • Designed for exceptional operational flexibility
  • Ultra-reliable baseline measurements

DF-745 SGMax

SERVOPRO Safe Area

The DF-745 SGMax is designed for the measurement of diverse gas mixtures in specialty gas blending applications.

  • Optimized for speciality gas blending
  • Accurate TDL analysis of trace moisture
  • An adaptable solution for diverse applications
  • Lower Detection Limit of 5 parts per billion
  • Database of 17 standard background gases
  • Virtually eliminates dry down times

DF-749

SERVOPRO Safe Area

Providing trace and ultra-trace moisture contaminant measurements in a variety of background gases, the DF-749 is ideal for quality checking of UHP gases used in LCD and LED manufacture.

  • Trace/ultra-trace moisture measurements
  • Checks purity in UHP electronic gases
  • Easily portable for cart or mobile use
  • Lower Detection Limit of 250 parts per trillion
  • Factory-calibrated for quick and easy installation
  • Minimised ongoing maintenance needs

DF-750

SERVOPRO Safe Area

The DF-750 is a trace/ultra-trace moisture analyzer optimized for measurements in the ultra-high-purity (UHP) gases used in 300mm semiconductor fabs.

  • A trace/ultra-trace moisture analyser
  • For purity checks in electronics-grade gases
  • Stable, highly accurate TDL measurements
  • 100ppt Lower Detection Limit
  • Low lifetime maintenance requirements

DF-750 ULTRA

SERVOPRO Safe Area

Delivering industry-leading trace/ultra-trace moisture measurements, the DF-750 ULTRA is optimized for quality monitoring in the ultra-high-purity (UHP) gases used in 300mm semiconductor fabs.

  • Delivers industry-best moisture measurements
  • Industry-leading 55 ppt Lower Detection Limit
  • Zero-drift stability extends calibration intervals
  • Measures in N2, H2, He, Ar and O2
  • Designed to meet exceptional gas purity standards

DF-760E

SERVOPRO Safe Area

Designed for quality control applications in UHP bulk gases, the compact DF-760E analyzer is a unique solution for the dual measurement of trace and ultra-trace moisture

  • For quality control in UHP bulk gases
  • Dual moisture and oxygen analysis
  • Trace and ultra-trace measurements
  • Non-depleting Coulometric O2 sensor
  • Robust TDL moisture sensing
  • Exceptional Lower Detection Limits

DF-760E ULTRA

SERVOPRO Safe Area

Designed for industry-leading quality control measurements in UHP bulk gases, the compact DF-760E ULTRA is a unique dual-analysis solution for trace and ultra-trace moisture and oxygen.

  • Dual moisture/oxygen analyser for UHP gases
  • Ideal for quality checking and leak detection
  • Lower Detection Limit of 55ppt moisture
  • Oxygen Lower Detection Limit of 45ppt
  • Combines Coulometric and TDL sensing
  • Broad detection ranges

FID

SERVOPRO Safe Area

With trace analysis capability, the FID is ideal for ASU safety and quality control applications.

  • Ideal for ASU safety and quality control
  • Robust Flame Ionization Detector analysis
  • Delivers trace Total Hydrocarbon measurements
  • An adaptable solution for diverse applications
  • Low-noise FID sensing for superior accuracy
  • Range of remote communication options

FluegasExact 2700

SERVOTOUGH Hazardous Area

Designed to measure O2 and COe in flue gases for improved combustion efficiency and reduced emissions.

The FluegasExact 2700 analyzer for effective combustion analysis
  • For combustion efficiency and reduced emissions
  • O2 only, or O2 & COe measurements in one sensor head
  • Ideal for all types of combustion processes
  • Robust, Industrial, fully-heated sensor head
  • Long-life, low-drift Oxygen sensing technologies
  • Close coupled, low flow extractive sampling design, extends product life

HFID

SERVOPRO Safe Area

Utilizes an internally heated oven set to 190°C (374°F) to maintain the sample gas above its dew point, for optimum performance in total hydrocarbon analysis (THC).

  • Highly sensitive trace hydrocarbon analyser
  • Ideal for vehicle/engine certification testing
  • Heated FID for volatile hydrocarbon concentrations
  • Delivers real-time, on-stream gas analysis
  • Cutter system removes non-methane hydrocarbons
  • Four user-definable measurement range options

Laser 3 Plus Combustion

SERVOTOUGH Hazardous Area

Unmatched installation flexibility plus cost and performance benefits, ready for fast, accurate and responsive measurements in combustion and process control.

Laser 3 Plus Combustion Tunable Diode Laser
  • Configured to measure O2, CO, or CO and CH4
  • Highly compact gas monitor
  • Ideal for in-situ cross-stack applications
  • Uses Wavelength Modulated Spectroscopy (WMS)
  • Easily installed by a single engineer
  • Reliable line lock cuvette technology

Laser 3 Plus Environmental

SERVOTOUGH Hazardous Area

Compact, high-performance Tunable Diode Laser (TDL) analyzer, specifically optimized for ammonia slip measurement

SERVOTOUGH Laser 3 Plus Environmental
  • Accurate NH3 measurements in DeNOx processes
  • Compliant with the US EPA PS18 standard
  • Exceptional benefits for clean air processes
  • In-situ cross-stack measurements
  • A highly compact gas analyser
  • Reliable line lock cuvette technology

Laser 3 Plus Process

SERVOTOUGH Hazardous Area

Optimized for the fast, accurate and responsive measurement of process oxygen (O2) in hot or hazardous conditions.

Laser 3 Plus Process Tunable Diode Laser (TDL) analyzer
  • Fast, accurate process control
  • Stable, repeatable O2 measurements
  • Exceptional performance in a compact design
  • Minimal installation and maintenance costs
  • Non-depleting TDL sensor technology
  • Reliable line lock cuvette technology

Micro i.s. 5100

SERVOFLEX Portables

Designed for the measurement of oxygen (O2) in potentially flammable gas samples. Certified to Zone 0 and Zone 1 and suitable for measuring percent levels of O2.

  • Portable analyser for percent levels of O2 (<21% O2)
  • Intrinsically safe – certified to Zone 0 and Zone 1
  • Analysis of O2 in both flammable and toxic samples
  • Ability to store up to 200 measurements
  • High-grade, long-life Li-Ion rechargeable batteries
  • Pumped or pressure driven sample gas options

MiniHD 5200

SERVOFLEX Portables

The MiniHD 5200 portable gas analyzer is a rugged, heavy duty analyzer designed to accurately measure the levels of O2, CO and CO2 within common gas mixtures.

SERVOFLEX MiniHD 5200
  • For field locations or light industrial applications
  • Measures O2, CO and CO2 in common gas mixtures
  • Portable analyser with a rugged and durable design
  • Uses digital Paramagnetic and Infrared sensing
  • Accurate measurements with no background interference
  • Intuitive, user-friendly interaction and interface

MiniMP 5200

SERVOFLEX Portables

The only truly portable battery-powered gas analyzer with MCERTS and TUV certification, offers single or dual measurement of oxygen (O2) and carbon dioxide (CO2).

  • High-performance oxygen and carbon dioxide analysis
  • Truly portable battery-powered gas analysis
  • Ideal for CEMS, with MCERTS and TUV certification
  • Accurate, long-life operation with minimal calibration
  • Combines Paramagnetic and Infrared technologies
  • Ideal for medical gas verification applications
Learn more Enquire now

MonoExact DF150E

SERVOPRO Safe Area

The MonoExact DF150E combines the reliability of Servomex’s tried and tested Coulometric oxygen sensor with a more user-friendly package.

  • Digital touchscreen and icon-driven interface
  • Tried and tested digital Coulometric oxygen sensor
  • Optimised for industrial gas applications
  • Measures oxygen across three ranges
  • Compact footprint for simple integration
  • No sensor zero calibration required
Learn more Enquire now

MonoExact DF310E

SERVOPRO Safe Area

Designed specifically for accurate measurements of oxygen in industrial gas (IG) applications.

  • Accurate measurements of oxygen and moisture
  • Designed for industrial gas applications
  • Tried and tested digital Coulometric oxygen sensor
  • Non-depleting Paramagnetic sensor option
  • Plug-and-play moisture sensor support
  • Analogue and digital communication options
Learn more Enquire now

MultiExact 4100

SERVOPRO Safe Area

A high-performance multi-gas analyzer designed to provide up to four simultaneous gas stream measurements.

SERVOPRO MultiExact 4100
  • Highly adaptable multi-gas analyzer
  • Provides up to four simultaneous measurements
  • Wide range of sensing technology options
  • Versatile solution for industrial and medical gases
  • Built-in support for moisture sensor
  • Optional advanced digital protocols

MultiExact 4200

SERVOPRO Safe Area

The MultiExact 4200 analyzes up to four gases simultaneously for Syngas and HyCO

  • For HyCO, Syngas, H2, and gas transfer applications
  • A high-specification multi-gas analyser
  • Measures up to four gas streams simultaneously
  • Combines industry-leading sensing technologies
  • Low cost of ownership and minimal maintenance
  • Intuitive-use icon-driven colour touchscreen

NanoChrome

SERVOPRO Safe Area

Incorporating the latest advances in gas sensing and signal processing methodology, the NanoChrome revolutionizes ultra-trace purity measurements.

  • Ultra-trace purity measurements in UHP gases
  • Designed for semiconductor manufacturing
  • Uses advanced Plasma Emission Detector sensor
  • Sensitive ProPeak software for high accuracy
  • Removes the need for flammable fuel gas
  • Comprehensive reporting and statistical analysis

NanoChrome ULTRA

SERVOPRO Safe Area

Using proven ultra-trace sensing, the NanoChrome ULTRA conquers the most stringent demands of the semiconductor industry, delivering a cost-effective solution compared to competing technologies.

  • The top choice for ultra-trace purity measurements
  • Designed for the semiconductor wafer industry
  • Superior measurements of ultra-high-purity gases
  • Highly specific, non-depleting PED sensing
  • ProPeak filtering for highly sensitive measurements
  • Removes the need for flammable fuel gas

NOx

SERVOPRO Safe Area

Measures NO or NO/NO2/NOx concentrations in industrial gas and vehicle emission applications.

  • Measures NO or NO/NO2/NOx concentrations
  • Uses time-proven Chemiluminescence sensing
  • Monitors industrial stationary sources emissions
  • Fast enough for emissions testing in engines
  • No vacuum pump requirement
  • Four user-definable measurement ranges

Oxy 1900

SERVOTOUGH Hazardous Area

The Oxy 1900 oxygen (O2) gas analyzer sets new standards of flexibility, stability and reliability from a single, cost-effective unit.

  • Zone 1/Division 1 hazardous area rated
  • Digital Paramagnetic O2 measurements
  • Heated sample gas compartment for stability
  • Unique patented FlowCube flow sensor for enhanced safety
  • Auto-validation / calibration option reduces hands-on maintenance
  • Intelligent sample vent pressure compensation option
Learn more Enquire now

OxyExact 2200

SERVOTOUGH Hazardous Area

The high-specification OxyExact 2200 O2 analyzer offers an unrivaled combination of precision, flexibility and performance for optimum process and safety control.

OxyExact 2200 high-specification O2 analyzer
  • Rated up to Zone 1/Division 1 hazardous area
  • High-specification Paramagnetic O2 analysis
  • Designed for demanding process & safety monitoring
  • Innovative three-compartment transmitter design
  • Link up to six transmitter units to one control unit
  • Samples flammable gas mixtures up to 100% O2

Plasma

SERVOPRO Safe Area

The Plasma delivers an accurate, highly stable and reliable measurement, with high sensitivity in the 0-1ppm range.

SERVOPRO Plasma
  • Analyses nitrogen in argon
  • Specifically designed for ASU plants
  • Unsurpassed stability and selectivity
  • High-specification Plasma Emissions Detector
  • Standard or high-purity setting modes
  • Reliable and accurate continuous monitoring

PureGas

SERVOPRO Safe Area

A getter-based purification unit designed for the purification of carrier gases used in Gas Chromatography (GC) and other analytical applications

SERVOPRO PureGas
  • Getter-based purification unit
  • Designed for carrier gases used in Gas Chromatography
  • Reduces outlet impurity levels to ppb or below
  • Removes impurities by forming irreversible chemical bonds
  • Efficient ceramic fibre insulation
  • Built to operate continuously, without servicing

SpectraExact 2500

SERVOTOUGH Hazardous Area

Flexible single and multicomponent gas analysis capability for corrosive, toxic and flammable sample streams.

  • Rugged, reliable photometric analysis
  • Designed for continually flammable samples
  • Suitable for hazardous area applications
  • Ideal for diverse gas sample types
  • Uses field-proven non-depleting technologies
  • Certified for gases

We’re proven experts for polyethylene

The Servomex team has a wide range of experience in supplying analytical systems for polyethylene production, delivering the accurate, reliable, and stable solutions your process requires.

Expert team

Our deep applications knowledge allows our experts to advise you on the best solution for your process requirements, with gas analysis solutions to meet your specific plant conditions.

Premium products

Servomex offers an extensive portfolio of accurate and reliable gas analysis technologies, providing you with the measurement technique that best suits each analysis point in your polyethylene production process.

Global support

All our gas analyzers are supported by a worldwide network of service personnel, delivering reliable analytical performance at optimum levels from day one, and backed by wide-ranging after-sales support products.

Meet the experts

Karen leads the Industrial Process and Emissions Business Unit in providing solutions which support our customers as they overcome the challenges of making their processes safer, cleaner, and more efficient.

Karen Gargallo, Business Unit Manager, IP&E

Keith Warren

Responsible for managing our oxygen analyzers in the Industrial Process & Emissions sector, Keith has been working with gas analysis solutions for more than 20 years, 12 of them at Servomex.

Keith Warren, Product Manager

Rhys Jenkins

Leading the life-cycle management of our Spectroscopic analyzer range, Rhys is responsible for the development of the markets they serve, and the strategic growth of those technologies.

Rhys Jenkins, IP&E Product Manager, Spectroscopic Analyzers

Overseeing the business development operations of our Industrial Process & Emissions team in China, Huiyu leads our pursuit of large international projects.

Huiyu Guan, Business Development Manager, IP&E, China

Stephen is responsible for managing the lifecycle of new Servomex Products, specifically, the introduction of new technologies into Servomex Analyzers. As STEM Team Leader he also coordinates the internal and external STEM program.

Stephen Firth, Product Manager- Strategic Projects

Working at Servomex for over 12 years, Maria specialises in gas analysis solutions for the industrial, medical, and semiconductor sectors across Europe, the Middle East, Africa, and India.

Maria-Katharina Mokosch, Senior Application Development Engineer

Find out more with our selection of polyethylene production resources

To learn more about our products and solutions for the polyethylene production process and other related applications, download our resources.

Analysis for polyethylene product quality

Analysis for polyethylene product quality

Polyethylene Production

Polyethylene Production

SERVOTOUGH SpectraExact 2500 Product brochure

SERVOTOUGH SpectraExact 2500 Product brochure

SERVOTOUGH OxyExact 2200 Product brochure

SERVOTOUGH OxyExact 2200 Product brochure

SERVOTOUGH Oxy 1900 Product brochure

SERVOTOUGH Oxy 1900 Product brochure

Servomex Systems Brochure

Servomex Systems Brochure

Servomex UK technical center

Not made up your mind yet? Let us convince you

We know it’s difficult to be certain you’ve found the right solution for your process. That’s why we recommend talking to one of our experts. They’ll give you peace of mind that the Servomex solution is the best you’ll find for your DRI process.

Enquire now

An ethical approach to business

Servomex’s values underpin everything we are and everything we do: they guide how we work, inform our decision-making and shape our culture.

Global commitments

Get the latest news, sign up to emails


© Copyright 2024 - Servomex is a Spectris company.
Click here to download your selected documents
